Growatt TPM-E Three Phase Smart Meter

Growatt TPM-E Three Phase Smart Meter

The Growatt Smart Meter is a dedicated solution for managing grid export limits and monitoring self-consumption, designed for use with Growatt solar and storage inverters. It features RS485 communication for direct, cost-effective connection to the inverter and easy DIN rail installation.

Note: This is a direct-wired energy meter and is not compatible with CT clamps. It is unsuitable for meter tails 25mm or larger—please consult your account manager for alternatives.

Key Features:

• Class 1 accuracy

• Plug-and-play setup

• LCD display for easy operation

• Compatible with Growatt solar and storage inverters

• Supports zero-export functionality

• Export control & self-consumption monitoring

• 3P4W grid type, 100A max current

• RS485 (Modbus RTU) communication

• 35mm DIN rail mount

• IP51 rated (indoor use)

• Dimensions: 72×94.5×65mm | Weight: 398g
