SMA Sunny Boy SB 4.0 1AV-41 Inverter - With WiFi
SMA Sunny Boy SB 4.0 1AV-41 Inverter - With WiFi
Couldn't load pickup availability
SMA Sunny Boy SB 4.0 1AV-41 Inverter - with WiFi
The Sunny Boy 3.0–6.0 guarantees maximum energy yields for private residences. Its integrated web interface allows for easy commissioning via a smartphone or tablet, while the SMA Smart Connected service ensures convenience for both PV system operators and installers.
New Feature: The integrated RS485 interface allows for the seamless addition of TS4-R module optimizers, with all communication and monitoring managed through the inverter.
Quick and Easy Installation: Weighing only 17.5kg, the Sunny Boy is lightweight and easy to install, occupying minimal space. The web interface enables quick commissioning via smartphone or tablet.
Intelligent Solar Power Generation: The Sunny Boy combines established features like SMA ShadeFix and SMA Smart Connected with integrated TS4-R communication for module optimization. The SMA ShadeFix system maximizes yields even in light shade. Free online monitoring is available through Sunny Portal and Sunny Places, and the dynamic active power limitation allows direct use of excess energy, reducing dependence on grid power.
Flexible Expansion: The Sunny Boy allows PV system operators to maintain maximum yields. Intelligent energy management and SMA storage solutions can be added at any time, ensuring the system adapts to increased solar power usage at home.
Please note: This model includes Wi-Fi functionality.
- Brand: SMA
- Rated Power: 4,000 W
- Max DC Power: 7,500 W
- Inverter Phase: 1
- Total Number of Strings: 4
- Number of MPP Trackers: 2
- MPPT Voltage Range / Rated Input Voltage: 140-500 V
- Start-up Input Voltage: 125 V
- Max Input Voltage: 600 V
- European Efficiency: 96.5%
- Integrated DC Switch: Yes
- Inverter IP Rating: IP 65
- Dimensions (Depth x Height x Width): 176 mm x 470 mm x 435 mm
- Product Weight: 17.5 Kg
- Grid Connection Standards: G99
- Warranty Period: 5 Years
SMA Sunny Boy 3.0-6.0 Data Sheet
SMA Sunny Boy 3.0-6.0 Installation Guide
SMA Sunny Boy 3.0-6.0 Quick Reference
SMA Sunny Boy 3.0-6.0 G98 Compliance Certificate
