Viridian

Viridian Clearline 5.0kW 1ph Inverter, 2 MPPT, With DC

Name: Viridian Clearline 5.0kW 1ph Inverter, 2 MPPT, With DC
Brand: Viridian
SKU: CSI5000
Price: 662.18 GBP
Availability: InStock

Viridian Clearline 5.0kW 1ph Inverter, 2 MPPT, With DC

£662.18 GBP

Sale Sold out

Tax included. Shipping calculated at checkout.

Quantity

Viridian Clearline 5.0kW 1ph Inverter, 2 MPPT, With DC

The Clearline CSI5000 is a lightweight and compact residential inverter. It has a maximum DC voltage of 600V and a start voltage of 50V. Equipped with two MPPTs, it supports a maximum input of 16A. The inverter also includes a DC switch, surge protection, and an optional AFCI.

Additionally, it employs natural convection cooling instead of a mechanical cooling system, enhancing safety and reliability by reducing maintenance needs and minimizing the risk of malfunctions due to fewer moving parts.

KEY FEATURES:

DC Connection
Maximum efficiency of 97.9%
Compact design
Smart control
Optional AFCI
Protection degree: IP66
Optional export limitation
10-year warranty

Brand	Viridian Clearline
Rated Power (W)	5,000
Max DC Power (W)	7,500
Inverter Phase	1
Total No. of Strings	2
No. of MPP Trackers	2
MPPT Voltage Range / Rated Input Voltage (V)	40-560
Start-up Input Voltage (V)	50
Max. Input Voltage (V)	600
European Efficiency (%)	97.3
Integrated DC Switch	Yes
Inverter IP Rating	IP66
Depth (mm)	143
Height (mm)	410
Width (mm)	350
Product Weight (Kg)	12.8
Grid Connection Standards (G98/G99/G100)	G100-2, G99
Warranty Period	10 Years
